Industrial Touch Mobile Computer

Lanodo Technology specializes in manufacturing custom Android industrial-grade Touch Mobile Computer. Our products are stable, durable, and easy to use, making them the ideal choice for custom industrial-grade Touch Mobile Computers.

Industrial Touch Mobile Computer

High-performance large-capacity storage system

Lanodo's customized products are widely used in various industries including logistics, power, transportation, agriculture, textiles, geology, petrochemicals, and natural gas.

  • Android 9.0
  • 8-core 2.0GHz
  • 5.5-inch HD Screen
  • 4G+64G Storage
  • 4G Full Netcom
  • IP68-level Protection
  • NFC Recognition
  • Equipped with Various Sensors

High-performance processors are used

MTK 8-core 64-bit 2.0 GHZ high-performance processor,

4GB RAM + 64B ROM large memory, multi-project performance test is smooth without stuttering

mobile computer mobile computer

Ergonomic design, professional and considerate

perfectly integrates ergonomic design with the requirements of professional industrial design. The front features a 5.5-inch large screen, with quick-scan buttons on both sides for easy one-handed operation by either left or right hand. The functional module layout is rational, facilitating users to quickly and effortlessly perform various operations.

Industrial Touch Mobile Computer Industrial Touch Mobile Computer

Rich data collection methods, accurate and fast.

Industrial-grade professional scanning engine, supports one-dimensional/two-dimensional scanning.Accurate and fast, safe data collection; can identify damaged, contaminated barcodes, improving work efficiency, suitable for various medical data collection.

mobile computer Data scanning code collection mobile computer Data scanning code collection

NFC reading and writing speed is fast and responsive

· Equipped with NFC reading and writing function, supporting ISO14443A/B ISO15693 NFC-IP1 NFC-IP2 and other protocol standards.

· It can be used for close-range device communication and high-security data transmission, with stable and fast connections and low power consumption, meeting the requirements for user authentication, electronic payments, and other applications.

mobile computer  NFC mobile computer  NFC

1.8m drop resistance

Within the operating temperature range, it can withstand multiple impacts from a height of 1.8m to the concrete ground on all six sides, and can still operate stably after 1000 consecutive 1.6ft/0.5m rolls, meeting the IEC rolling specifications, earthquake resistance and drop resistance.

Rugged Touch Mobile Computer Rugged Touch Mobile Computer
Product specifications
    • System Configuration
    • Processor:
      Octa-core 2.0GHz high-performance processor
    • System:
      Android 9.0
    • Memory:
      3GB+32GB (standard), 4GB+64GB (optional)
    • Display and Touch Screen:
      IPS 5.45 inches (1440720) multi-touch full-fit
    • Camera:
      Front 5 million pixels, rear 13 million pixels, supports autofocus
    • SIM Slot:
      Triple slot, supports dual SIM cards or single SIM card + TF card, TF card supports up to 128GB
    • Sensors:
      Gravity, proximity/light sensors
    • Buttons:
      3 buttons: Power button, left Scan button, right Scan button
    • Battery:
      Built-in 3.85V 5000mAh high-performance lithium polymer battery
    • Audio:
      Receiver, speaker, and main and secondary microphones
    • Charging:
      Type-C charging and bottom pin charging, supports 10W fast charging
    • Vibration Motor:
      Built-in vibration motor, supports scanning vibration feedback
    • Scanner Module:
      Supports mainstream scanners such as Symbol 4710, Honeywell 6603, Newland CM60, MINDA ME5066, etc.
    • Communication Interface:
      Type-C1, supports OTG, supports headphone function
    • RF Parameters
    • Wireless Network:
      2G(GSM):B2/B3/B5/B8
      3G(WCDMA):B1/B5/B8
      4G(FDD-LTE):B1/B3/B5/B8/B20
      4G(TDD-LTE):B34/B38/B39/B40/B41
    • Bluetooth:
      Bluetooth 5.0, supports BLE
    • Location:
      GPS/AGPS/GLONASS/QZSS
    • WLAN:
      802.11 ac/a/b/g/n (2.4GHz+5GHz dual-band Wi-Fi)
    • NFC:
      13.56MHz, supports ISO14443A/14443B/15693, etc.
    • Structural Dimensions
    • Dimensions:
      158mm*76mm*13.8mm
    • Weight:
      240g (including battery)
    • Environmental Parameters
    • Operating temperature:
      -20°C55°C (excluding battery)
    • Storage temperature:
      -30°C70°C (excluding battery)
    • Operating humidity:
      0~95% (non-condensing)
    • Protection level:
      IP68
    • Drop specification:
      1.5-meter multiple drops on concrete
    • Drum drop specification:
      1000 times 0.5-meter drum drop
    • Electrostatic protection:
      15 KV (air discharge), ±8 KV (contact discharge)
    • Development Support
    • Development language:
      Java
    • Development environment:
      Eclipse/Android Studio
    • Standard Accessories:
      USB data cable1, fast charging power adapter1, wrist strap1
